FEATURES:
1. Initial Range:Up to 100 of load cell Output.
2. Tare Range: 100% of the scale capacity.
3. Zero setting:Operated through push button when the scale is stable.
4. Auto Zero Tracking:Range and Time delay are adjustable.
5. kg/lb conversion.
6. 1 inch bright & large LED display.
7. Over-load indication.
8. Low battery indication.
9. Power:DC6V/10AH
10. Built-in Rechargeable Battery:Life100~120 hours. auto Cut-off battery charger Provided
11. With controller.
SPECIFICATIONS (UT-A/B)
|
MODEL |
CAPACITY |
DIVISION |
UNIT(mm) |
N.W |
|||
|
L |
L1 |
W |
H |
||||
|
UT-A-006 |
600Kg |
0.2Kg |
630 |
200 |
220 |
255 |
19Kg |
|
UT-A-010 |
1000Kg |
0.5Kg |
630 |
200 |
220 |
255 |
19Kg |
|
UT-A-015 |
1500Kg |
0.5Kg |
630 |
200 |
220 |
255 |
19Kg |
|
UT-A-020 |
2000Kg |
1Kg |
630 |
200 |
220 |
255 |
19Kg |
|
UT-A-030 |
3000Kg |
1Kg |
630 |
200 |
220 |
255 |
19Kg |
|
UT-B-050 |
5000Kg |
2Kg |
900 |
200 |
220 |
255 |
54Kg |
|
UT-B-075 |
7500Kg |
2Kg |
900 |
268 |
248 |
325 |
54Kg |
|
UT-B-100 |
10000Kg |
5Kg |
900 |
268 |
248 |
325 |
54Kg |
|
UT-B-150 |
15000Kg |
5Kg |
900 |
268 |
248 |
325 |
54Kg |
