Features:
- OIML R60 C3 approved
- NTEP 10000 III-L approved
- Stainless steel
- Protection class IP68 as hermetically sealed
- Patent rocker pin design for self restoring and anti-rotation
- Low self-weight and easy installation
- Excellent durability
- Available on request of EEx ib IIC T4
- Optionally available with service temperature range up to 200°C (413°F).
Specification
- Rated capacity t 20,30,50,100,200,250
- Rated output mV/V 2 ± 0.002
- Non repeatbility %R.C. ≤0.01
- Hysteresis %R.C. ≤0.02 ≤0.04
- Non linearity %R.C. ≤0.01 ≤0.04
- Creep (30min) %R.C. ≤0.02 ≤0.03
- Zero balance %R.C. ≤1
- Temp. Compensated range °C -10~+40
- Operating temp. Range °C -30~+65
- Temp. coefficient on output %Load/ °C ≤0.002
- Temp. coefficient on zero balance %R.C./°C ≤0.002
- Input resistance Ω1160 ± 10
- Output resistance Ω1000 ± 3
- Insulation resistance M5000(50V DC)
- Recommended voltage V (DC/AC) 5~15
- Max. excit. voltage V (DC/AC) 20
- Safe overload %R.C. 125
- Ultimated overload %R.C. 300
- Protection class IP68
- Cable length m 13
- Rated capacity t 20,30,50,100,200,250
